IMR 21700 5300 mAh PULSE 25 A CONTINUE 17 A CELL CHARACTERISTICS Shape Cylindrical Can Steel Diameter 21;05 ± 0.10 mm Height 70.35 ± 0.10 mm Weight 68.1 ± 1.0 gr
Capacity Typical 5300 mAh Minimum 4800 mAh Cell voltage Charge 4.2V Discharge 2.5V Charge current Standard 1.5 A Maximum 3.5 A Charge time Standard 3.55hr Maximum 25A Discharge current 25A with 80° Temperature cut Internal resistance AC (1KHZ) 23 m Ω (max) Ambiant Charge 0°C to 45°C Température Discharge -20°C to 55°C Energy density Volumetric 808 Wh / l Gravimetric 288 Wh / Kg
